HTC VIVE XR Elite — All-in-One & PC VR Headset

The HTC VIVE XR Elite is a convertible all-in-one XR headset that works completely untethered or as a full PC VR headset. Powered by the Qualcomm Snapdragon XR2 chip, the VIVE XR Elite pairs a 3840 x 1920 combined-resolution display, up to 110° field of view and a 90 Hz refresh rate with real depth-sensing RGB colour passthrough for mixed reality. Detach the rear battery cradle and the headset folds down into lightweight, glasses-style XR goggles you can take anywhere.

Why the VIVE XR Elite stands out

Convertible all-in-one and PC VR design

Use the VIVE XR Elite as a standalone VR headset with the rear battery cradle attached for balanced weight, or remove the cradle to wear it as a compact pair of XR glasses. When you want desktop-class graphics, connect to a gaming PC over USB-C or Wi-Fi 6E and stream PC VR with low latency through VIVE Streaming.

Colour passthrough mixed reality

Four wide-field-of-view tracking cameras, a 16 MP RGB colour camera and a dedicated depth sensor blend the physical and virtual worlds, so you can see your room, your desk and your controllers while you play.

Finely tuned visuals

Adjustable IPD (interpupillary distance) from 54 to 73 mm, plus a diopter dial for each lens, let you match the headset to your eyes and leave your glasses off.

Your VIVERSE portal

Put the headset on and step straight into VIVERSE to socialise, show art, learn, work, create and play. Skeletal-level hand tracking lets you navigate, click, drag, scroll and type with natural hand and finger movements, with no controllers in your hands.

Key features

• Convertible form factor: full standalone XR headset or portable XR glasses
• Qualcomm Snapdragon XR2 processor with 12 GB RAM and 128 GB storage
• 1920 x 1920 pixels per eye (3840 x 1920 combined), up to 110° FOV, 90 Hz
• RGB colour passthrough with true depth sensing for mixed reality
• Wireless and wired PC VR through VIVE Streaming (Wi-Fi 6E or USB-C)
• Adjustable 54–73 mm IPD and per-lens diopter dials
• Controller-free skeletal hand tracking
• Hot-swappable 24.32 Wh battery cradle that doubles as a rear counterweight
• Dual speakers and dual microphones with echo cancellation
• 6 DoF inside-out tracking, up to a 10 x 10 m play space

Technical specifications

Highlights	Convertible, compact, high-performance all-in-one XR headset that transforms into portable immersive glasses; strong graphics performance and high-resolution passthrough in a small form factor; customisable viewing comfort with IPD and diopter dials.
Resolution	1920 x 1920 pixels per eye (3840 x 1920 combined)
Headset tracking	Inside-out 6 DoF tracking
Refresh rate	90 Hz
Field of view	Up to 110 degrees
Audio	Dual microphones with echo cancellation; integrated speakers
Processor	Qualcomm Snapdragon XR2
Memory / storage	12 GB RAM / 128 GB storage
Connectivity	1x USB 3.2 Gen-1 Type-C peripheral port; 1x USB 3.2 Gen-1 Type-C power port; Bluetooth 5.2 + BLE; Wi-Fi 6 and 6E
Sensors	4 tracking cameras; 16 MP RGB camera; depth sensor; G-sensor; gyroscope; proximity sensor
Ergonomics	Balanced weight for long sessions; ergonomically curved rear battery module used as a counterweight; magnetically attached front gasket; eye-comfort adjustment for a 54–73 mm IPD range
Battery	24.32 Wh battery cradle: removable and hot-swappable; lightweight lithium-polymer gel chemistry; fast recharging; up to about 2 hours of continuous use
Tracking	VIVE inside-out tracking; play space of up to 10 x 10 m recommended

Controller specifications

Sensors	Hall sensors on the trigger and grip buttons; capacitive sensors on the trigger, joystick and thumb-rest area; gyroscope with G-sensor
Inputs	Ergonomic grip button; analogue trigger; A/B and X/Y buttons; system / menu buttons; joystick
Battery	Up to 15 hours of battery life; built-in rechargeable battery charged over USB-C

Play-area requirements

Standing / seated	Both supported
Room scale	Play area of up to 10 x 10 m recommended; minimum play area 1.5 x 1.5 m (standing)

What’s in the box

• VIVE XR headset
• Battery cradle
• Controller (L)
• Controller (R)
• Lanyards x 2
• Microfibre pouch
• Top strap
• USB Type-C to Type-C cable
• USB Type-A to Type-C cable x 2
• Lens protection card
• Documentation (quick-start guide, safety guide, warranty card)

HTC VIVE XR Elite FAQ

Does the HTC VIVE XR Elite work as a PC VR headset? Yes. You can stream PC VR wirelessly over Wi-Fi 6E or connect by USB-C using VIVE Streaming for low-latency, high-fidelity PC VR games.

Is the VIVE XR Elite a standalone headset? Yes. It runs on the Qualcomm Snapdragon XR2 chip and works fully untethered, with no PC or phone required.

Does it have colour passthrough for mixed reality? Yes. A 16 MP RGB colour camera and a dedicated depth sensor provide real-scale colour passthrough and precise environment awareness.

Can I use the VIVE XR Elite without controllers? Yes. Skeletal-level hand tracking lets you navigate menus and interact using only your hands.

Do I need glasses with it? Most users do not. The adjustable 54–73 mm IPD and per-lens diopter dials let you tune focus for each eye.

How long does the battery last? Around 2 hours of continuous use per battery cradle. The cradle is hot-swappable, so a spare extends your session without shutting down.
